Removing the screen
Step 1: Unlock the Screen
Turn off the printer's power. Tilt the screen upwards and press on the unlock icon until the screen slides to the right and frees itself from the printer frame.

Step 2: Disconnect the Cable
Remove the screen cable from the port behind the screen by pinching the sides to depress the buttons to release the locking mechanism.

Installing the Screen
Step 1: Connect the Cable
Plug the screen cable into the port on the back of the new screen. Ensure the connector is fully seated and locked in place.

Step 2: Install the Screen
Feed the excess ribbon cable into the frame through its slot and align the four locking tabs into their respective holes. Once inserted, move the screen to the left to lock it into place.

Verifying Success
Turn on the printer's power. If the screen lights up, shows no abnormalities, and touch input is registered normally, the replacement is completed.
