Bundle Details — Included Items:
Standalone- Heygear Reflex 2 Pro
Resin Bundle- Heygear Reflex 2 Pro + 5KG Resin (PAH10)
Pulsing Release Bundle- Heygear Reflex 2 Pro + Plusing Release Module
All-In-One- Heygear Reflex 2 Pro + 5KG Resin (PAH10) + Plusing Release Module

SKU:
Resin- MA.002.789(A)
Plusing Release Module- Pulsing Release Module without resin tank
---

A Larger Build Volume for Seamless Production
The Reflex 2 Pro offers a significantly expanded build capacity, delivering a 2.3× larger volume than the standard Reflex model. With an impressive 350 mm Z-height, it enables taller, more complex, and more consolidated parts to be produced in a single print. This increased vertical space supports a wider variety of applications—from functional prototyping to batch production—allowing users to print larger components without splitting models or compromising structural integrity.

1032 OptiZone Light Engine, Pioneered by HeyGears

The Reflex 2 Pro is powered by HeyGears’ next-generation 1032-zone OptiZone Light Engine, engineered for exceptional precision and consistency in light projection. Each of the 1032 zones is independently controlled, allowing the system to cure resin with pinpoint accuracy. This targeted illumination improves surface quality, reduces unintended exposure, and minimizes resin residue—ultimately lowering tank filtration frequency and enhancing production efficiency.

Precise Light Projection for Superior Print Quality- By shaping and controlling the light output at a micro-zone level, the system ensures accurate curing across all features, from fine details to large surfaces. This level of precision improves dimensional accuracy, sharpens edges, and produces smoother finish quality, even in complex or densely packed builds.

Customized Collimating Lens Stack- The light engine incorporates 1032 individual collimating lenses combined with a dual-sided microlens array containing 468,000 microlenses. Together, these optical layers generate highly collimated, uniform light that delivers consistent exposure across the entire build area. The result is improved print stability, reduced distortion, and more reliable performance during long production runs.

Optimized Multi-Part Nesting- By matching the projected light area to the exact contours of every model, the OptiZone system reduces unnecessary exposure between nested prints. This not only enhances dimensional accuracy but also improves batch-printing efficiency—making the Reflex 2 Pro ideal for high-density workflows where precision and throughput are equally important.

Upgraded Amber Screen Pro, Enhanced Batch-Production Reliability
The Amber Screen Pro delivers a 10% energy transmission rate—double that of standard LCD screens—supporting light intensities up to 35 W/m² for faster exposure and compatibility with higher-performance resins. Its large-molecule liquid crystal layer provides strong UV resistance, ensuring over 6,000 hours of stable operation, backed by a 1-year warranty. Reinforced support pillars offer 100× greater pressure resistance, allowing reliable printing with high-viscosity materials. With 86,000+ zone AI calibration using the MASK algorithm, the screen achieves up to 94% light uniformity and high dimensional accuracy. Its modular design also allows quick, easy replacement when needed.

Precision FOC Motor Module, Industrial-grade Performance
The Reflex 2 Pro’s FOC Motor Module delivers closed-loop motion control with 25,600 microsteps per revolution, enabling highly accurate and stable positioning even under heavy load or high-speed printing. When paired with the C5-grade Z-axis module, it maintains repeat positioning accuracy within ±2 μm under loads up to 80 kg, minimizing layer deviations and ensuring consistent print quality. Compared to traditional stepper motors, the FOC system provides smoother, more reliable movement at high speeds, with 99.6% of layer thickness errors kept within ±2 μm—making it well-suited for demanding, industrial-scale batch production.

Intelligent Temperature Control: Enhancing 3D Printing Success Rates
The Reflex 2 Pro uses a smart scraper-assisted heating system that warms resin quickly and maintains it at an optimal temperature throughout the print. This reduces sedimentation, minimizes residue buildup, and improves overall print stability. Heating resin from 10 °C to 22 °C takes just six minutes—68% faster—significantly shortening pre-print preparation time. With an integrated heater and high-precision temperature sensor, the system maintains resin temperature within ±1 °C, ensuring consistent curing conditions and higher printing success rates.

Intelligent Features, Boosting Print Success
The Reflex 2 Pro integrates advanced intelligent systems designed to improve reliability and reduce manual intervention. Its ultrasonic resin-level sensor measures the liquid surface with ±0.5 mm accuracy, enabling precise automatic refilling throughout the print. High-sensitivity force sensors detect residue as small as 0.15 mm with 0.01 N precision and automatically pause printing to prevent failures. A floating build platform with just 0.15° deviation eliminates gaps up to 240 µm for fully automated leveling, ensuring consistent first-layer performance. The die-cast unibody base enhances structural rigidity, removes cumulative part tolerances, and improves Z-axis repeatability for stable, accurate printing.
